Automotive Electronics and Actuators Trainer

Price on application
Electude E-LearningCompact, versatile learning system for automotive electronics and actuators. All components can be freely wired according to real motor vehicle electrical circuits. Contains: 2 x fuse, switch, 5 V DC power source, 2 x precision shunt, pulse-width-frequency generator for simulation of control devices, capacitor, potentiometer, rectifier diode, Z-diode, thyristor, NPN transistor, Mosfet transistor, 2 x lamp, relay, proportional solenoid valve, commutator motor. Laboratory front panel with console housing for use on the table or in A4 desk frames. Extensive digital worksheets available for Electude E-Learning System.
Delivery time 6 - 8 weeks

Innovative laboratory trainer for automotive electronics and actuators. The components can be freely wired to numerous typical automotive electrical circuits.

  • Overview
  • Features
  • Clear presentation of available components with colored imprint
  • Wire any circuit - as with conventional plug-in modules
  • Electronically protected components
  • Extensive digital worksheets available for Electude e-learning system
  • Learning content
  • Getting to know vehicle-typical electronic components and actuators according to equipment
  • Interpreting typical voltage values in vehicle-related circuits
  • Multimeter and oscilloscope as measuring devices
  • Equipment
  • Laboratory trainer in console housing for use on the table or in DIN A4 support frame
  • 2 x fuse, switch, 2 x precision shunt, pulse width frequency generator for simulation of control units
  • 5 V DC voltage source, capacitor, 3 x resistors, potentiometer, rectifier diode, Z diode, thyristor
  • NPN transistor, field effect transistor, 2 x lamp, relay, proportional solenoid valve, collector motor
  • 65 x sockets for wiring and measuring, 4 x sockets for power supply
Manufacturer:
Category: Lab-Trainers
Item number: 12020160
EQF-Level‍: Level 2Level 3Level 4
E-Learning‍: Electude
Power Supply‍: 10 - 15 V DC (3 A)
Product weight‍: 2,50 Kg
Dimensions ( length width height )‍: 29,70 26,60 12,00 cm
